Performance meets simplicity
MAN Turbochargers
MAN turbochargers are designed to deliver peak performance throughout their working lives – in some of the harshest conditions encountered anywhere in the world. This is achieved by combining three elements: simplicity, flexibility and reliability. For example, we develop and build our turbochargers to make installation, operation, servicing and maintenance as easy and efficient as possible. This reduces your initial capital investment and results in lower lifecycle costs.
Due to high prices and sustainability restrictions, ship owners and operators are looking at ways ofreducing fuel consumption and emissions. Our turbocharger technologies are committed to help you achieve your goals.
Find your perfect fit: Our range of turbochargers
Ready for the future with enhanced performance and efficiency – The TCP series of radial turbochargers can achieve maximum pressure ratios of up to 7.
- 800 - 5,800 kW
Making the most of optimized flow – Delivering an impressive 20 % increase in specific flow, the TCF radial turbocharger offers a big potential to use smaller or less turbochargers.
- 1,000 - 7,200 kW
The MAN TCT is specifi cally designed for IMO Tier III two-stroke engines. The latest axial turbocharger generation offers significant downsizing together with easier maintenance and higher charging efficiency.
MAN TCA turbochargers are high-performance solutions characterized by simple maintenance and long overhaul intervals.
- 5,400 - 32,400 kW
The latest generation of MAN TCR turbochargers offers reduced size and weight while delivering greater efficiency, performance, and reliability.
MAN ETB
MAN’s ETB is explicitly designed for EcoEGR applications where the blower will run continuously in both Tier III and Tier II Eco mode. This results in a compact and cost optimized design with highest availability.
- 1,000 - 7,200 kW
MAN TCX
With the TCX series MAN Energy Solutions has developed a turbocharger, especially suited to two-stage turbocharging of four-stroke diesel and gas engines.
- 8,500 - 23,300 kW
MAN ECOCHARGE
As a compact two-stage unit, the MAN ECOCHARGE delivers outstanding turbocharging efficiency. A variety of product types and sizes are available, ensuring the perfect turbocharger-to-engine fit.
Higher scavenging air pressure and efficiency allow improved Miller timing, enabling compliance with IMO Tier III emissions legislation.
- Lower specific fuel oil consumption (SFOC)
- Lower exhaust emissions (NOx)
- Compact design
- Improved dynamic response
MAN VTA
MAN VTA (variable turbine area) allows charge air delivery to be optimized for the charge air demand precisely, seamlessly, and continuously at all engine loads and speeds.
- Reduced consumption
- Reduced emissions
- Easy application
Test your equipment in our Performance Center
Our Turbocharger Performance Center enables customers from the turbomachinery, turbocharger or other thermal machines sectors to put their equipment to the acid test. Our equipment will deliver measurement results at its best. And it goes without saying, that protection of our customers' sensitive data is guaranteed at all times.
Strong performance worldwide
Low- and high-speed turbocharger output range
MAN turbochargers are in operation on more than 65,000 two-stroke propulsion and four-stroke auxiliary and propulsion engines running on MDO, HFO, and gas. The range covers engine outputs from 600 kW up to 30,000 kW per turbocharger and are specially matched to every engine. We develop and build our turbochargers to make installation, operation, servicing, and maintenance as easy and efficient as possible. This reduces your initial capital investment and results in lower life cycle costs.
MAN PrimeServ: 24/7 service and support worldwide, 365 days a year
Join the more than 65,000 turbochargers that are looked after by MAN PrimeServ – providing a unique one-stop service for engines and turbochargers around the globe. Our technicians are always available to answer questions, assist in troubleshooting, and get your turbochargers up and running in no time – wherever and whenever you need them.
How you benefit:
- Fast, reliable, and expert customer support
- Prompt 24-hour OEM spare part delivery
- Individual O&M contracts
- Global service – 24 hours a day, 365 days a year
Contact us
Talk to our experts
Continue reading
-
MAN TCApdf, 509 KB
-
MAN TCFpdf, 460 KB
-
MAN TCPpdf, 461 KB
-
MAN TCRpdf, 1836 KB
-
MAN TCTpdf, 403 KB
-
SCR-HP - Exhaust gas treatment from Turbochargerspdf, 1391 KB
-
Turbocharger Power Systems A guide to maximum engine performancepdf, 11914 KB
